Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)

Facnor Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)

42 255 SEK
42 255 SEK
Hoppa till produktinformation
Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
  • Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)
Facnor Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)

Facnor Conversion drum kit FlatDeck FD280 SX47 Ø22mm pin (replacement of LS/LX200-290 drum)

42 255 SEK
42 255 SEK
I lager
  • Optimum luff length
  • Delivered with a bottom Ø22mm pin + short link plates
  • High load bearing FD Drum
  • Anodized mechanism, waterproof (no specific maintenance)

Conversion drum kit FD280
with
Ø22mm
pin includes :
1x FD280 Sx47 drum (delivered with the webbing+furling line)
1x bottom Ø22mm pin
2x 76mm link plates
1x stainless steel fairlead set (1x articulated + 3x fixed ones)
This kit enables to replace one LS200 or LS290 or LX200 or LX290 drum fitted with SX39 foil sections.
It corresponds to the rep 44 on list of the FD01 exploded drawing and is composed by Rep 1 + Rep 14+ Rep 15 +Rep 16 + Rep 23.
Please refer to installation manual for assembly; always check in case of turnbuckle fitting that the cage can fit inside the FD drum.



Technical specifications
Weight (g): 14090
